ZWO ASI715MC Color CMOS Astronomy Camera
ZWO ASI715MC Color CMOS Astronomy Camera
SKU:ZWO-ASI715MC
Available Soon
Couldn't load pickup availability
Product Description
The ZWO ASI715MC is a high-resolution colour planetary astronomy camera built around Sony’s IMX715 sensor. With 8.46MP resolution, 1.45μm pixels and 45.1 FPS, it is designed for capturing detailed lunar, planetary and solar-system images. Its USB 3.0 interface supports fast image transfer, while the low read noise and 80% peak QE help preserve fine details during high-speed imaging.
Technical Specifications
| Specification | Details |
|---|---|
| Sensor | Sony IMX715 CMOS |
| Sensor Type | Colour |
| Sensor Size | 1/2.8" |
| Sensor Dimensions | 5.6 × 3.2 mm |
| Resolution | 3864 × 2192 |
| Megapixels | 8.46 MP |
| Pixel Size | 1.45 μm |
| ADC | 12-bit |
| Peak QE | 80% |
| Read Noise | 0.72e⁻ |
| Full Well Capacity | 6.03Ke |
| Maximum FPS | 45.1 FPS |
| Interface | USB 3.0 |
| Shutter | Rolling shutter |
| Cooling | Uncooled |
| Best For | Lunar, planetary & solar-system imaging |
What Comes in the Box?
The ASI715MC package includes the camera and the required connection/accessory components for telescope imaging. The camera supports 1.25-inch, 2-inch and M42×0.75 connections.
FAQs
1. What is the ZWO ASI715MC best for?
The ASI715MC is particularly suitable for lunar, planetary and solar-system astrophotography.
2. What sensor does the ASI715MC use?
It uses Sony's IMX715 colour CMOS sensor with a 1/2.8-inch format.
3. What is the resolution of the ASI715MC?
It provides 3864 × 2192 resolution, equivalent to approximately 8.46MP.
4. What is the maximum frame rate?
The ASI715MC can reach 45.1 FPS at full resolution.
5. Does the ASI715MC have cooling?
No. The ASI715MC is an uncooled colour astronomy camera designed primarily for high-speed planetary imaging.
