ZWO ASI183MM-P Cooled Monochrome CMOS Astronomy Camera
ZWO ASI183MM-P Cooled Monochrome CMOS Astronomy Camera
SKU:ZWO-ASI183MM-P
Available Soon
Couldn't load pickup availability
Product Description
The ZWO ASI183MM-P Cooled Monochrome CMOS Astronomy Camera is a high-resolution cooled astronomy camera designed for detailed deep-sky and scientific imaging. It features the Sony IMX183 monochrome CMOS sensor with 5496 × 3672 resolution, approximately 20.18 megapixels, and 2.4 μm pixels.
Its monochrome sensor is well suited to astrophotographers who use LRGB and narrowband filters to capture detailed images of galaxies, nebulae, and other deep-sky targets. The camera also features a two-stage TEC cooling system that helps reduce thermal noise during long exposures.
With USB 3.0 connectivity, a built-in DDR3 buffer, low read noise, and high quantum efficiency, the ASI183MM-P provides a capable platform for high-resolution astrophotography.
Technical Specifications
| Specification | Details |
|---|---|
| Model | ZWO ASI183MM-P |
| Sensor | Sony IMX183 Monochrome CMOS |
| Sensor Type | 1-inch Mono CMOS |
| Resolution | 5496 × 3672 |
| Megapixels | Approx. 20.18 MP |
| Pixel Size | 2.4 μm |
| Peak QE | Approx. 84% |
| Read Noise | Approx. 1.6e⁻ |
| Full Well Capacity | Approx. 15Ke⁻ |
| Shutter | Rolling Shutter |
| ADC | 12-bit |
| Exposure Range | 32 μs – 2000 s |
| Cooling | Two-stage TEC |
| Cooling Performance | Up to approximately 45°C below ambient |
| Interface | USB 3.0 |
| USB Hub | 2 × USB 2.0 |
| Guide Port | ST4 |
| DDR3 Buffer | 256 MB |
| Back Focus | 6.5 mm |
| Weight | Approx. 410 g |
| Best For | Deep-sky, LRGB and narrowband imaging |
What Comes in the Box?
- ZWO ASI183MM-P Camera Body
- USB 3.0 Cable
- 2 × USB 2.0 Cables
- 1.25" Nosepiece
- M42 Adapter
- M48 Adapter
- Dust Caps
- Quick Start Guide
Why Buy from Sky Deep Co.?
Choose the ZWO ASI183MM-P from Sky Deep Co. for genuine ZWO astronomy equipment backed by local guidance and support in Pakistan. Sky Deep Co. is an official authorized ZWO dealer in Pakistan, offering genuine products along with product consultation, warranty support, and after-sales assistance. Sky Deep also states that its authorized-dealer status can be verified through ZWO's official dealer locator.
Sky Deep focuses specifically on astronomy equipment and astrophotography, helping customers choose cameras, filters, telescopes, and accessories according to their imaging goals and existing setup.
FAQs
Is the ZWO ASI183MM-P a monochrome camera?
Yes. It features a Sony IMX183 monochrome CMOS sensor designed for detailed astrophotography.
Is the ASI183MM-P cooled?
Yes. It uses a two-stage TEC cooling system to reduce sensor temperature and thermal noise during long exposures.
What is the resolution of the ASI183MM-P?
The camera provides 5496 × 3672 resolution, delivering approximately 20.18 megapixels.
Is the ASI183MM-P suitable for narrowband imaging?
Yes. Its monochrome sensor works well with LRGB and narrowband filters for detailed deep-sky imaging.
Does the ASI183MM-P have an ST4 guide port?
Yes. The camera includes an ST4 guide port along with USB connectivity.
