ZWO ASI183MC Color CMOS Astronomy Camera (Uncooled)
ZWO ASI183MC Color CMOS Astronomy Camera (Uncooled)
SKU:ZWO-ASI183MC
Available Soon
Couldn't load pickup availability
Product Description
The ZWO ASI183MC Color CMOS Astronomy Camera is a high-resolution uncooled color astronomy camera designed for detailed astrophotography. It features Sony's back-illuminated IMX183 color CMOS sensor with 5496 × 3672 resolution, delivering approximately 20.18 megapixels with fine 2.4 μm pixels.
With a peak quantum efficiency of approximately 84% and low read noise, the ASI183MC provides strong sensitivity for capturing detailed images of deep-sky objects. Its color sensor also makes it convenient for one-shot color astrophotography without requiring separate LRGB filters.
The camera can reach up to 19 FPS at full resolution, making it suitable for planetary, lunar, solar imaging with proper filtration, live viewing, and selected deep-sky applications. USB 3.0 connectivity provides fast image transfer during imaging sessions.
Technical Specifications
| Specification | Details |
|---|---|
| Model | ZWO ASI183MC |
| Sensor | Sony IMX183 Color CMOS |
| Sensor Type | 1" Color CMOS |
| Resolution | 5496 × 3672 |
| Megapixels | Approx. 20.18 MP |
| Pixel Size | 2.4 μm |
| Sensor Size | 13.2 × 8.8 mm |
| Diagonal | 15.9 mm |
| Peak QE | Approx. 84% |
| Read Noise | Approx. 1.6e⁻ |
| Full Well Capacity | 15Ke⁻ |
| ADC | 12-bit / 10-bit |
| Maximum Frame Rate | 19 FPS |
| Shutter | Rolling Shutter |
| Exposure Range | 32 μs–2000 s |
| Cooling | Uncooled |
| Interface | USB 3.0 / USB 2.0 |
| Back Focus | 6.5 mm |
| Weight | Approx. 140 g |
| Best For | Deep-Sky, Lunar & Planetary Imaging |
What Comes in the Box?
- ZWO ASI183MC Color Camera
- USB 3.0 Cable
- USB 2.0 Cable
- 1.25" Nosepiece
- 2" Adapter
- M42 × 0.75 Adapter
- Dust Cap
- Quick Start Guide
Why Buy the ZWO ASI183MC from Sky Deep Co.?
Choose the ZWO ASI183MC from Sky Deep Co. for genuine ZWO astronomy equipment with local product guidance and support in Pakistan. Sky Deep Co. is an official ZWO retailer/authorized partner in Pakistan, offering genuine ZWO products and astronomy-focused assistance for selecting cameras, filters, telescopes, and accessories. Sky Deep's current ZWO collection identifies the ASI183MC as an uncooled color camera.
Sky Deep focuses on astronomy and astrophotography equipment, helping customers select suitable products according to their telescope, imaging targets, and experience level. This makes the ASI183MC a practical option for users looking for a high-resolution color camera without the additional complexity of a cooled system.
FAQs
Is the ZWO ASI183MC a color camera?
Yes. It uses Sony's IMX183 color CMOS sensor for one-shot color astrophotography.
Is the ASI183MC cooled?
No. The ASI183MC is the uncooled version of the ASI183 color camera series.
What is the resolution of the ASI183MC?
It provides 5496 × 3672 resolution, equivalent to approximately 20.18 megapixels.
What is the maximum frame rate?
The ASI183MC can reach up to 19 FPS at full resolution.
Is the ASI183MC suitable for deep-sky imaging?
Yes. Its high-resolution sensor, approximately 84% peak QE, and small 2.4 μm pixels make it suitable for detailed deep-sky imaging, as well as lunar and planetary applications.
